TENFLY TD-PMN156FCJ1

15.6″ Portable Monitor|FHD|Anti-glare surface|Dual USB Type-C|mini-HDMI®|kickstand

Overview

TENFLY TD-PMN156FCJ1 is a 15.6-inch ultra-slim portable monitor designed for versatile connectivity and vibrant QLED visuals. With a 1920×1080 FHD resolution, 1200:1 contrast ratio, and 45% NTSC color gamut, it delivers crisp, vivid images whether you’re gaming, working, or streaming. Weighing just 805g and only 13mm thin, it fits easily in any bag, making it ideal for travel and mobile productivity. With dual Type-C ports and Mini HDMI, it seamlessly connects to laptops, gaming consoles, and mobile phones, offering plug-and-play convenience across multiple platforms.

Key Features

  • 15.6″ Full HD QLED panel with anti-glare surface for clear, comfortable viewing
  • Lightweight and ultra-slim design (805g, 13mm) for effortless portability
  • Wide 178° viewing angles with FFS technology and 1200:1 contrast ratio
  • Dual USB-C and Mini HDMI ports for flexible multi-device compatibility
  • Built-in stereo speakers and 3.5mm headphone jack for immersive audio
  • VESA 75x75mm mountable and equipped with a built-in stand for flexible use
  • Compatible with PS4, Xbox, Switch, PC, laptops, Android phones, and MacBooks
  • Power-efficient operation with ≤10W consumption and ≤1W standby

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

ModelTENFLY TD-PMN156FCJ1
DisplayScreen Size15.6″
Panel Type15.6″  QLED
Resolution1920×1080
Display Area344.16 (H)×193.59 (V) mm
Surface TreatmentAnti-glare
Display ModeFFS, Normally Black
Brightness Factory Control Maximum280cd/m² (Typ.)
Contrast Ratio1200:1（Typ.)
Response Time5ms
Ten-Point TouchNA
Pixel Pitch179.25(H)×179.25(V) um
Aspect Ratio16:9
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Refresh Rate45Hz
Color GamutNTSC 45% （Typ.)
HDR Image RenderingNA
FREE-SYNCYES
Interface TypeMini HDMI2.0 Input/Audio and Video Transmission
USB  Type CExternal Power Supply/Audio and Video Transmission
USB  Type CExternal Power Supply/Audio and Video Transmission
Headphone Jack3.5mm Headphone Jack
Control ButtonsButton ModeThree-Phase Wheel Button + Power Button
AppearanceWeightAppearance Material – ColorABS/Black
Appearance Size362*227*13
Packaging Box Size450*325*65mm
Bare Weight805g
Packaging Weight1980g
Hardware Supported FeaturesPS4/XBOX/SWITCH/PC Host/TV BOX/Digital CameraMini HDMI to HDMI
Laptops TabletsMini HDMI to Mini HDMISome models support direct connection via Type-C
TYPE-C 3.1 Full Function Android PhonesCompatible with Samsung, Huawei, Nut, Black Shark, Sony, One Plus, etc.One-line solution: Mobile mode/PC mode
Ordinary SmartphonesNA
Apple PhonesRequires an Apple adapter
Apple MACBOOKMost models support display capabilities
Speakers1W*2(8Ω)
Power ConsumptionOn: ≤10WStandby≤1W, Off≤1W
VESA Wall Mount Specification2 Hole 75*75
Operating EnvironmentOperating Temperature and Humidity0ºC~50ºC  10～85%RH（Non-condensing）
