TENFLY TD-MN340WQC

34″ WQHD Curved VA Gaming Monitor, 100Hz Refresh Rate, 3440×1440 Resolution, 21:9 Display, Support HDR&FreeSync, Ergonomic Stand

Overview

TENFLY TD-MN34 Curved Monitor delivers an immersive ultra-wide viewing experience with a 21:9 aspect ratio and a stunning 3440×1440 resolution. Featuring a 1500R curved VA panel, 100Hz refresh rate, and HDR support, this monitor is designed to enhance both work efficiency and entertainment immersion. With FreeSync support, low blue light technology, and ergonomic adjustments, it combines performance, comfort, and style for professionals and gamers alike.

Key Features

  • 34″ 1500R curved screen + WQHD (3440×1440), immersive surround field of view, 33% screen space increase
  • 100Hz + FreeSync + Overdrive, smooth and tear-free gaming/audio experience
  • HDR100 + 3000:1 contrast ratio, cinematic light and dark details and vivid colors
  • Ergonomic stand, lift/tilt adjustment, no fatigue after long-term use
  • Low blue light + DC dimming, more comfortable for long-term use
  • All-round interface, HDMI 2.0×2 + DP 1.2 + audio output

Application Scenarios

Immersive Gaming – 1500R curved WQHD screen with 100Hz refresh rate and FreeSync delivers ultra-smooth, tear-free gameplay with enhanced field of view

Professional Content Creation – HDR100 and 3000:1 contrast ratio provide accurate color reproduction and fine details for video/photo editing

Home Entertainment Hub – Ultra-wide cinematic display with vivid HDR visuals transforms movie watching into a theater-like experience

Productivity Powerhouse – 33% more screen space boosts efficiency for multitasking with documents, spreadsheets and creative tools

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

                      PanelProduct ModelTENFLY TD-MN34
OC Brand/ModelCSOT SG3402H02-3
Panel Resolution3440 *1440
Refresh Rate100Hz
Flat/CurveCurve (1500R)
Screen size (diagonal)34”
Aspect Ratio21:9
Viewable Screen Size (Diagonal)86.4CM
Pixel Pitch0.07725mm(H)*0.23175mm(V)
Panel TypeVA
Display Area797.22mm(H)*333.72mm(V)
Brightness300±30CD/㎡
Contrast Ratio (Typ.)3000:1
Response Time (Typ.)5ms(OD)
View Angle(H/V) (Typ.)178°(H)/178°(V)(CR≥10)
View Angle(H/V) (min)170°(H)/170°(V)
Horizontal Refresh Rate(KHz)31 to 148kHz
Vertical Refresh Rate(Hz)40 to 100Hz
Bandwidth(MHz)533MHz(Typ.)
Max Resolution3440 ×1440 100Hz
Recommended Resolution3440 ×1440 60Hz
Color Depth16.7M
Color Gamut (sRGB)NTSC: 72%
HDCP SupportYES
HDRHDR100
G-SyncNA
FreeSyncYES
          Mechanical (ME)Front BezelABS, black, fine texture finish
Rear PanelNA
Rear ShellABS, black with red decorative ring, fine texture finish
Rear Shell Decorative PanelABS, black, fine texture finish
Middle FrameNA
ButtonsABS, black, fine texture finish
BaseAluminum alloy, black painted, fine texture finish (Y-shape)
Stand ColumnAluminum alloy, black painted, fine texture (cylindrical)
Height AdjustmentYES
Pivot-5°~+20° (±3°)
SwivelNA
Ambient LightNA
VESA Mount100*100mm
Tempered GlassNA
CartonKraft paper
Monitor BagPE bag
Protective MaterialUpper and lower EPE foam
Rear NameplateSilver dragon adhesive
Outer Box StickerGlossy adhesive sticker
           Electronics (EE)MotherboardHK.M.RT2795E04
Overdrive (OD)YES
Black Level EqualizerYES
Sync TechnologyFreeSync
Software FeaturesLow Blue Light
DC DimmingYES
Signal InterfacesHDMI, DP
Video InputHDMI 2.0*2, DP 1.2*1
Audio OutputEarphone*1
Functional PortUSB 2.0*1
SpeakersNA
Power InputAC 180-240V~50/60Hz 1.0A Max
Adapter OutputDC 12V, 4A
Crosshair OverlayYES
Boot LogoIPASON
OSD StyleTBA
Default LanguageChinese
Power Consumption (Working)≤45W
Power Consumption (Standby)0.5W
  AccessoriesManualYES
Warranty CardYES
Power CableNA
Signal CableDP*1.5M
  Dimensions & WeightMonitor (with Stand)808(W)x230(D)x436~551(H)mm
Monitor (without Stand)808(W)x62(D)x362(H)mm
Carton Dimensions575(W)x125(D)x420(H)mm(Subject to final product)
Packaging ListMonitor, Stand Support, Base, Power Adapter, Manual，DP Cable (1.5m)
Net Weight5.8Kg (Subject to final product)
Gross Weight8Kg (Subject to final product)
   CertificationsCCCCertified
Energy EfficiencyGrade 2
EnvironmentalRoHS
Energy SavingNA
