TENFLY TD-AIOW2513
27″ Gaming AIO PC | Intel i7 Powerhouse with Expandable Storage | Immersive Design for Gaming, Creativity, and Work
Overview
TENFLY is a forward-looking brand committed to delivering reliable, customizable, and visually striking all-in-one computing solutions. Designed with both performance and aesthetics in mind, our 27” Gaming-Inspired AIO PC brings a perfect balance of functionality and immersive design. Whether for gaming lounges, creative professionals, or premium office setups, this model reflects TENFLY’s dedication to ergonomic engineering and flexible deployment.
Key Features
Application Scenarios
Customization Options
TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.
Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.
Product Name | TD-AIOW2513 |
Product Color | Black/white (optional) |
Operating System | Windows 10/11 64-bit |
Display Manufacturer/Model | AUO M270HVN02.0 (optional) |
Display Size/Ratio | 27-inch 16:9 LED backlight widescreen |
Display Mode | VA |
Diagonal Size | 68.6cm |
Resolution | 1920×1080 |
Refresh Rate | 60Hz |
Default Color Temperature | 6500K(±750K) |
Screen Size | 597.6(H) x 336.15(V)mm |
Dot Pitch | 0.31125(H)×0.31125(V) mm |
Display Color | 16.7M |
Brightness (Typ.) | 250 cd/㎡ |
Contrast | 3000:1[Typ.] |
Response Time | 20ms[Typ.] |
Viewing Angle | 178°(H)/178°(V)[Typ.] (CR≧10) |
Uniformity | 75%[Typ.] & 70%[Min.] |
CPU | Intel Core 12th Generation I7-13700 (Supports Intel 12th/13th Generation LGA1700 series integrated graphics processors) |
CPU Frequency | 2.1GHz (Max turbo frequency 5.2GHz) |
Level 3 Cache | 30MB |
Production Process | 10nm |
Number of Cores | Sixteen cores and twenty-four threads |
Display Chip | Intel HD Graphics 770 |
TDP Power Consumption | 65W |
Motherboard Model | JW H610I (optional) |
Port Image | ![]() |
Chipset | Intel H610 |
Memory Interface | SO-DIMM DDR4 memory slot*2 (Supports 2666/2933/3200MHz memory frequency) 32G MAX |
Storage Interface | M.2 2242/2280 SSD*1, 2.5inch SATA SSD/HDD*1 |
Network Interface | RJ-45(10/100/1000M Ethernet Lan)*1 |
WIFI Interface | M.2 2230*1 |
USB Port | USB3.2*2, USB3.0*2 |
Function Port | COM*1 |
Video Port | HDMI OUT*1 |
Audio Ports | Headphone jack ∮3.5mm*1 Microphone jack ∮3.5mm*1 |
Power Interface | DC-in (5525) 19V input x1 |
Memory | DDR4 PC4-3200MHz 8G/16GB/32G (Optional) |
Hard Disk | M.2 2280 SATA/NVMe 256G/512GB/1TB (optional) |
Graphics | Integrated Graphics |
WIFI | RTL8821CE, 1R1T, dual antenna (2.4GHz/5GHz 802.11 a/b/g/n/ac, Bluetooth 4.2) |
Extended USB Port | USB2.0*2(side) |
Speaker Function | 8Ω/3W * 2 |
Camera | 300W, with MIC (optional) |
Power Adapter | 19Vdc,6.32A,120W |
Decorative Strips | ABS, black, textured |
Frame | ABS, black, textured |
Back Shell | ABS, white, textured |
Back Cover Decorative Sheet | PVC, black, grid pattern |
Back Shell Decorative Strip | ABS, red, grid pattern |
I/O Bezel | SGCC, the metal itself |
Bracket | Aluminum profile + ABS, black + white, red decorative sheet |
Base | Aluminum alloy (U-shaped), black, textured |
Product Net Weight/Gross Weight | 5.6kg / 8.4kg (without keyboard and mouse) |
Product Size | With base bracket: L614*W233*H465mm Without base bracket: L614*W57*H363mm (Subject to the final product) |
VESA Mount | 75mmx75mm |
Axis Angle | -5°~15°(±3°) |
Height Adjustment | NA |
Horizontal/Vertical Rotation | NA |
