TENFLY TD-AIOH2489
23.8″ Energy-Efficient AIO | Intel N5095 Quad-Core | 3000:1 VA Panel | Dual Storage (M.2+2.5″) | COM+4×USB | 52mm Ultra-Slim VESA Wall-Mount
Overview
TENFLY AIO PC is a well – designed computing solution that combines style and functionality. Powered by an i5 – 10400 CPU and running on Windows 10 64 – bit, it’s suitable for a variety of tasks, from daily office work to multimedia entertainment. The TD-AIOH2489 design saves space, and with multiple connectivity options and a set of safety certifications, it’s a reliable choice for home and office use.
Key Features
Application Scenarios
Customization Options
TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.
Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.
| Product Name | TD-AIOH2489 |
| Product color | Black/silver |
| Operating System | Windows 10 64-bit (only supports UEFI mode system) |
| Display Size/Ratio | 23.8-inch 16:9 LED-backlit widescreen |
| Display Mode | VA |
| Diagonal Size | 60.5CM |
| Resolution | 1920×1080@60Hz |
| Refresh Rate | 60Hz |
| Default Color Temperature | 6500K |
| Screen Size | 527.04(H) x 296.46(V)mm |
| Dot Pitch | 0.2745*0.2745mm |
| Display Color | 16.7M |
| Brightness (Typ.) | 220±20 cd/m² |
| Contrast | 3000:1[Typ.] / 1800:1[Min.] |
| Response Time | 16ms [Tr+Td] |
| Color Gamut | NTSC: 69% |
| Viewing Angle | 178°(H)/178°(V)(CR≥10) |
| Uniformity | 75%[Typ.] & 70%[Min.] |
| CPU | Intel N5095 |
| CPU Frequency | 2.0GHz |
| Number of Cores | Quad cores and four threads |
| Display Chip | Intel® UHD Graphics |
| TDP Power Consumption | 15W |
| Motherboard Model | SK Thin mini 5095-AIO |
| Chipset | Intel N5095 |
| Memory Interface | SO-DIMM DDR4 memory slot*2 (supports 2666/2400/2133MHz memory frequency) |
| Storage Interface | M.2 2242/2280 SSD*1, 2.5inch SATA SSD/HDD*1 |
| Network Interface | RJ-45 (10/100/1000M Ethernet Lan)*1 |
| WIFI Interface | M.2 2242 wireless network card interface*1 |
| USB Port | USB 3.1*2, USB 2.0*2 |
| Function Port | COM*1 |
| Video Port | HDMI OUT*1 |
| Audio Ports | Headphone jack ∮3.5mm*1 Microphone jack ∮3.5mm*1 |
| Power Interface | DC-in (5525) 12V input x1 |
| Memory | Kingpark DDR4 2666MHz 4G |
| Hard Disk | To be determined |
| Graphics | Integrated Graphics |
| WIFI Model | NFA821 (RTL 8821CE) |
| Extended USB Port | USB 2.0*2(side) |
| Speaker Function | 8Ω/3W * 2 |
| Camera | N/A |
| Power Adapter | External desktop adapter, DC 12V 6A (72W) |
| Front Frame | SGCC, black spray paint, textured surface |
| Frame | PC+ABS, black, textured |
| Middle Frame | ABS, black, textured |
| Back Shell | ABS, black, textured + glossy |
| Bracket | Square quick-release portable, aluminum alloy, black spray paint, textured surface |
| Base | Square, aluminum alloy, black spray paint, textured surface |
| VESA Mount | 100 mm*100 mm |
| Axis Angle | -5°~15°（±3°） |
| Height Adjustment | NA |
| Horizontal/Vertical Rotation | NA |
| Product Net Weight/Gross Weight | 4.5 kg / 6.5 kg (Subject to the final product) |
| Product Size | 542(W)x 200(D)x 410(H)mm (with stand) 542(W)x 52(D)x 325(H)mm(without stand) |
