TENFLY TD-AIO238F99

23.8″ IPS Display with 98% sRGB All-in-One PC丨DDR5 & Ryzen™ 7000 Ready丨Rich I/O with Type-C丨Tailored for Multimedia & Business

Overview

TENFLY TD-AIO238F99 is a high-performance 23.8″ All-in-One PC that blends sleek design with powerful hardware flexibility. Equipped with an FHD wide-view display and a wide selection of Intel® and AMD CPU platforms, it caters to a broad range of usage needs—from educational and government projects to business and multimedia creation.

With a slim form factor, dual storage options, and comprehensive I/O ports, this AIO unit is ideal for work environments requiring efficiency, style, and adaptability.

Key Features

  • 23.8” Full HD Display
  • Available in VA/IPS panel with 1920×1080 resolution, optional 60Hz or 100Hz refresh rate, and 98% sRGB color coverage
  • Multiple CPU Options
  • Intel® 12th/13th Gen Desktop CPUs (LGA1700)
  • Intel® N-Series Mobile CPUs (N95/N100/N300/i3-N305, etc.)
  • AMD Ryzen™ 6000/7000 Series Mobile CPUs
  • Memory & Storage
  • DDR4/DDR5 RAM, up to 32GB
  • Dual storage: M.2 NVMe SSD + 2.5” SATA HDD/SSD
  • Connectivity
  • HDMI, USB3.2, optional full-featured Type-C
  • COM/VGA optional for industrial applications
  • Gigabit LAN, Wi-Fi 5/6, Bluetooth 4.2/5.0/5.2
  • OEM Customization Available
  • Custom logo, housing, interface layout, OS/software, and packaging for projects or branding needs

Application Scenarios

  • Education & Public Sector
  • Cost-effective configurations for classrooms and e-learning, with strong OS compatibility and remote teaching support
  • Corporate & Administrative Use
  • Intel® LGA or Ryzen™ platforms deliver solid multitasking and document handling for offices and government deployments
  • Creative & Multimedia Work
  • AMD Ryzen™ 7 series or Intel® i7 options provide advanced processing for design, marketing, and digital content tasks
  • Retail, POS & Industrial Control
  • COM/VGA ports and stable long-term availability make this model suitable for kiosks, terminals, and factory systems

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

Product ModelTD-AIO238F99ATD-AIO238F99BTD-AIO238F99C
Product ColorBlackBlackBlack
Display Size/Ratio23.8 inch/16:923.8 inch/16:923.8 inch/16:9
Operating SystemWindows 10/11Windows 10/11Windows 10/11
Display ModeVA/IPS (Optional)VA/IPS (Optional)VA/IPS (Optional)
Resolution1920*10801920*10801920*1080
Refresh Rate60Hz/100Hz (Optional)60Hz/100Hz (Optional)60Hz/100Hz (Optional)
Color GamutsRGB coverage 98%sRGB coverage 98%sRGB coverage 98%
Viewing Angle178°(H)/178°(V)(CR≥10)178°(H)/178°(V)(CR≥10)178°(H)/178°(V)(CR≥10)
Brightness220 cd/m² (Typ.)220 cd/m² (Typ.)220 cd/m² (Typ.)
MotherboardH610//
CPUSupport Intel 12/13 generation LGA1700 series integrated graphics processorsN5095/N95/N100/N150/N200/N300/I3-N305/I5-12450H/I7-12700H/I5-13420H/I7-13620HAMD R5-6600H/R5-7640HS/R7-7840H/R7-8745HS/R7-8845HS
Memory 2*SO-DIMM DDR4 (support 2666/2933/3200MHz) 32G MAX1*SO-DIMM DDR4 (supports 2666/2933/3200MHz)16G MAX2*SO-DIMM DDR5 (Support 4800/5200/5600MHz)32G MAX
Hard DiskSupport M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1Support M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1Support M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1
WIFI&BTSupport Wi-Fi 5/Wi-Fi 6, BT 4.2/5.0/5.2Support Wi-Fi 5/Wi-Fi 6, BT 4.2/5.0/5.2Support Wi-Fi 5/Wi-Fi 6, BT 4.2/5.0/5.2
I/O PortsDC IN*1, HDMI*1, COM*1 (optional VGA), USB 3.2*3/TYPE-C*1 (optional USB 3.2*4), RJ-45 (1000 M)*1, Line out*1, MIC in*1DC IN*1, HDMI*1, COM*1 (optional VGA), USB 3.2*2, USB 2.0*2, RJ-45 (1000 M)*1, Line out*1, MIC in*1DC IN*1, HDMI*1, VGA*1 (optional DP), USB 3.2*3/TYPE-C (full function)*1 (optional USB 3.2*4), RJ-45 (1000 M)*1, Line out*1, MIC in*1
I/O Ports PicturePorts PicturePorts Picture
Extension InterfaceUSB2.0*2USB 2.0*2USB 2.0*2
VESA100mm*100mm100 mm*100 mm100mm*100mm
Machine Size with StandL540mm*W200*H409mmL540 mm*W200 mm*H409 mmL540mm*W200*H409mm
Machine Size without StandL540mm*W48mm*H323mmL540 mm*W48 mm*H323 mmL540mm*W48mm*H323mm
Packing SizeL600mm*W145mm*H515mmL600 mm*W145 mm*H515 mmL600mm*W145mm*H515mm
Net Weight4.7 kg4.7 kg4.7 kg
Gross Weight6.5 kg6.5 kg6.5 kg
