TENFLY TD-AIO238F89

23.8″ FHD Wide Screen All-in-One PC丨Supports Intel® & AMD Ryzen™丨Dual-Channel Memory丨VESA Wall-Mounted Ultra-Thin Design

Overview

TENFLY TD-AIO238F89 is a 23.8” Full HD All-in-One PC that offers the perfect balance of size, performance, and adaptability. Built to support Intel® LGA1700 desktop processors, Intel® N-series mobile CPUs, and AMD Ryzen™ 6000/7000 series, this model delivers outstanding versatility for business workstations, educational deployments, and creative studios alike.

With dual-storage capacity, Wi-Fi 6 support, and a wide selection of I/O ports, the AIO is an efficient and professional solution for a wide range of applications.

Key Features

  • 23.8” Full HD Display
  • Optional VA or IPS panel with 1920×1080 resolution, 60Hz/100Hz refresh rate, and 98% sRGB color gamut for accurate, vibrant visuals.
  • Multi-Platform CPU Compatibility
  • Intel® LGA1700 12th/13th Gen – High-performance desktop solutions
  • Intel® N5095/N100/i3-N305/i7-12700H – Power-efficient mobile platforms
  • AMD Ryzen™ R5/R7 6000/7000 Series – Ideal for high-load creative tasks
  • Flexible Memory & Storage
  • DDR4 or DDR5 memory up to 32GB
  • M.2 NVMe SSD + 2.5” HDD/SSD dual-storage support
  • Rich I/O Interfaces
  • HDMI, USB 3.2, full-function Type-C (optional), Gigabit LAN
  • Optional COM, VGA or DP ports for extended use scenarios
  • Audio input/output, flexible layout for multiple deployments
  • Stable Wireless Connectivity
  • Optional Wi-Fi 5 / Wi-Fi 6
  • Bluetooth 4.2 / 5.0 / 5.2 depending on platform
  • OEM/ODM Customization Ready
  • Available for logo, housing color, system image, port configuration, packaging, and more — ideal for project tenders and branding.

Application Scenarios

  • Government & Office Terminals
  • Support for desktop-level CPUs and Gigabit LAN makes it a strong fit for enterprise software environments and administrative use.
  • Education & Public Projects
  • Cost-effective N-series configurations with good display quality are perfect for classrooms, computer labs, and training rooms.
  • Creative Studios & Multimedia Work
  • With AMD Ryzen™ and DDR5 support, this model delivers smooth performance for content creation, digital media, and design work.
  • Retail, Kiosk & Signage
  • Optional legacy ports and full-HD display suit retail POS systems, smart kiosks, and digital signage terminals.

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

Product ModelTD-AIO238F89ATD-AIO238F89BTD-AIO238F89C
Product ColorBlack/Silver (optional)Black/Silver (optional)Black/Silver (optional)
Display Size/Ratio23.8 inch/16:923.8 inch/16:923.8 inch/16:9
Operating SystemWindows 10/11Windows 10/11Windows 10/11
Panel TypeVA/IPS (optional)VA/IPS (optional)VA/IPS (optional)
Resolution1920*10801920*10801920*1080
Refresh Rate60Hz/100Hz (optional)60Hz/100Hz (optional)60Hz/100Hz (optional)
Color GamutsRGB coverage 98%sRGB coverage 98%sRGB coverage 98%
Viewing Angle178°(H)/178°(V)(CR≥10)178°(H)/178°(V)(CR≥10)178°(H)/178°(V)(CR≥10)
Brightness220 cd/m² (Typ.)220 cd/m² (Typ.)220 cd/m² (Typ.)
MotherboardH610//
CPUSupport Intel 12/13 generation LGA1700 series integrated graphics processorsN5095/N95/N100/N150/N200/N300/I3-N305/I5-12450H/I7-12700H/I5-13420H/I7-13620HAMD R5-6600H/R5-7640HS/R7-7840H/R7-8745HS/R7-8845HS
Memory2*SO-DIMM DDR4 (support 2666/2933/3200MHz) 32G MAX1*SO-DIMM DDR4 (support 2666/2933/3200MHz) 16G MAX2*SO-DIMM DDR5 (support 4800/5200/5600MHz) 32G MAX
Hard DiskSupport M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1Support M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1Support M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1
WIFI&BTSupport Wi-Fi 5/Wi-Fi 6, BT4.2/5.0/5.2Support Wi-Fi 5/Wi-Fi 6, BT 4.2/5.0/5.2Support Wi-Fi 5/Wi-Fi 6, BT 4.2/5.0/5.2
I/O PortsDCIN*1, HDMI*1, COM*1 (optional VGA), USB3.2*3/TYPE-C*1 (optional USB3.2*4), RJ-45 (1000M)*1, Line out*1, MIC in*1DCIN*1, HDMI*1, COM*1 (optional VGA), USB 3.2*2, USB 2.0*2, RJ-45 (1000M)*1, Line out*1, MIC in*1DCIN*1, HDMI*1, VGA*1 (optional DP), USB 3.2*3/TYPE-C (full function)*1 (optional USB 3.2*4), RJ-45 (1000M)*1, Line out*1, MIC in*1
I/O Ports PicturePorts PicturePorts PicturePorts Picture
Extension PortsUSB 2.0*2USB 2.0*2USB 2.0*2
VESA100 mm*100 mm100 mm*100 mm100 mm*100 mm
Machine Size with StandL540 mm*W200 mm*H430 mmL540 mm*W200*H430 mmL540 mm*W200 mm*H430 mm
Machine Size without StandL540 mm*W56 mm*H323 mmL540 mm*W56 mm*H323 mmL540 mm*W56 mm*H323 mm
Packing SizeL655 mm*W170 mm*H505 mmL655 mm*W170 mm*H505 mmL655 mm*W170 mm*H505 mm
Net Weight4.9 kg4.9 kg4.9 kg
Gross Weight6.8 kg6.8 kg6.8 kg
