TENFLY TD-AIO238F09

23.8″ FHD Slim Bezel All-in-One PC丨Triple CPU Options丨Compact Design丨Ideal for Office, Education & Retail Projects

Overview

TENFLY TD-AIO238F09 is a compact and efficient 23.8-inch All-in-One PC designed to meet a wide spectrum of commercial and institutional needs. With its slim bezel design, lightweight body, and support for Intel® LGA1700 desktop CPUs, Intel® N-series mobile processors, and AMD Ryzen™ 6000/7000 series, this AIO delivers excellent performance and versatility in a space-saving form.

Perfectly suited for office terminals, school labs, and commercial displays, it combines full HD visuals with multiple CPU and I/O options to adapt to diverse deployment requirements.

Key Features

  • 23.8” Full HD Slim Display
  • Narrow-bezel VA/IPS panel (optional), 1920×1080 resolution, 60Hz or 100Hz refresh rate, 98% sRGB coverage for vibrant output
  • Multiple Performance Platforms
  • Intel® 12/13th Gen LGA1700 – For robust performance in enterprise settings
  • Intel® N5095 to i7-13620H – Efficient, scalable options for balanced workloads
  • AMD Ryzen™ 5/7 6000/7000 Series – Tailored for content and multitasking
  • Efficient Memory & Storage Support
  • DDR4/DDR5 RAM up to 32GB
  • M.2 NVMe SSD + 2.5” HDD/SSD for dual-drive capability
  • Functional Connectivity
  • HDMI, USB 3.2, optional Type-C (full function), Gigabit LAN
  • Optional COM, VGA or DP for extended business use
  • Audio I/O, flexible layout for multiple use cases
  • Wireless & Expansion Ready
  • Wi-Fi 5 / Wi-Fi 6, Bluetooth 4.2 / 5.0 / 5.2
  • VESA mountable, 100×100mm for flexible installations
  • OEM/ODM Custom Services Available
  • Supports brand logo, housing design, port configuration, system preload, and packaging customization

Application Scenarios

  • Office Workstations & Government Desktops
  • The compact design and scalable performance options make it ideal for administrative work, CRM/ERP terminals, and standard desktop deployments.
  • Educational Labs & Computer Training Rooms
  • With efficient Intel® N-series CPUs and slim bezels, this AIO improves space utilization and visibility in classrooms and public learning facilities.
  • Retail POS & Display Terminals
  • Optional legacy ports and VESA mounting support make it a strong choice for retail checkouts, kiosks, and interactive screens.
  • Project-Based Deployments
  • Affordable pricing, modular specs, and branding flexibility make the TD-AIO238F09 an excellent candidate for OEM/ODM tenders and government IT rollouts.

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

Product ModelTD-AIO238F09ATD-AIO238F09BTD-AIO238F09C
Product ColorBlackBlackBlack
Display Size/Ratio23.8 inch/16:923.8 inch/16:923.8 inch/16:9
Operating SystemWindows 10/11Windows 10/11Windows 10/11
Panel TypeVA/IPS (optional)VA/IPS (optional)VA/IPS (optional)
Resolution1920*10801920*10801920*1080
Refresh Rate60Hz/100Hz (optional)60Hz/100Hz (optional)60Hz/100Hz (optional)
Color GamutsRGB coverage 98%sRGB coverage 98%sRGB coverage 98%
Viewing Angle178°(H)/178°(V)(CR≥10)178°(H)/178°(V)(CR≥10)178°(H)/178°(V)(CR≥10)
Brightness220 cd/m² (Typ.)220 cd/m² (Typ.)220 cd/m² (Typ.)
MotherboardH610//
CPUSupport Intel 12/13 generation LGA1700 series integrated graphics processorsN5095/N95/N100/N150/N200/N300/I3-N305/I5-12450H/I7-12700H/I5-13420H/I7-13620HAMD R5-6600H/R5-7640HS/R7-7840H/R7-8745HS/R7-8845HS
Memory2*SO-DIMM DDR4 (support 2666/2933/3200MHz) 32G MAX1*SO-DIMM DDR4 (support 2666/2933/3200MHz) 16G MAX2*SO-DIMM DDR5 (support 4800/5200/5600MHz) 32GB MAX
Hard DiskSupport M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1Support M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1Support M.2 2280 NVMe/SATA SSD*1, 2.5-inch SSD/HDD*1
WIFI&BTSupport Wi-Fi 5/Wi-Fi 6, BT 4.2/5.0/5.2Support Wi-Fi 5/Wi-Fi 6, BT4.2/5.0/5.2Support Wi-Fi 5/Wi-Fi 6, BT 4.2/5.0/5.2
I/O PortsDCIN*1, HDMI*1, COM*1 (optional VGA), USB 3.2*3/TYPE-C*1 (optional USB 3.2*4), RJ-45 (1000M)*1, Line out*1, MIC in*1DCIN*1, HDMI*1, COM*1 (optional VGA), USB 3.2*2, USB 2.0*2, RJ-45 (1000M)*1, Line out*1, MIC in*1DCIN*1, HDMI*1, VGA*1 (optional DP), USB 3.2*3/TYPE-C (full function)*1 (optional USB 3.2*4), RJ-45 (1000M)*1, Line out*1, MIC in*1
I/O Ports PicturePorts PicturePorts PicturePorts Picture
Extension PortsUSB 2.0*2USB 2.0*2USB 2.0*2
VESA100 mm*100 mm100 mm*100 mm100 mm*100 mm
Machine Size with StandL540 mm*W200 mm*H430 mmL540 mm*W200 mm*H430 mmL540mm*W200 mm*H430 mm
Machine Size without StandL540 mm*W56 mm*H323 mmL540 mm*W56 mm*H323 mmL540 mm*W56mm*H323 mm
Packing SizeL655 mm*W170 mm*H505 mmL655 mm*W170 mm*H505 mmL655 mm*W170 mm*H505 mm
Net Weight4.9 kg4.9 kg4.9 kg
Gross Weight6.8 kg6.8 kg6.8 kg
