Lenovo AIO-A807

27″ QHD All-in-One Powerhouse | 12th Gen Intel® Core™ i5 Optional | Dual Storage & 32GB RAM | WiFi 6 & VESA Mount

Overview

Lenovo AIO-A807 is a top – notch computing device engineered to meet diverse usage demands. Sporting a 27″ VA panel with a 2560×1440 resolution at 60Hz refresh rate, it presents a crystal – clear visual spectacle. It offers options for a high – powered Intel Core 12th Generation i5 – 12400 CPU, enabling it to handle a wide array of tasks with ease.

Key Features

  • 27″ 2K high-definition screen, 2560×1440 VA panel
  • 4000:1 high contrast, 178° wide viewing angle, vivid colors, and support VESA wall mounting
  • HDMI, COM port, Gigabit network port, dual-band Wi-Fi, USB3.2/3.0/2.0, easily connect to office/teaching/entertainment equipment
  • Optional 12th generation i5-12400 processor (6 cores and 12 threads), dual DDR4 slots (up to 32GB) + M.2/SATA dual hard disk slots, worry-free multi-tasking and storage expansion

Application Scenarios

Media & Design Studios: high-contrast QHD display enhances photo/video editing and content creation

Business Command Centers: handles data-intensive tasks and multitasking with desktop-grade CPU/RAM

Digital Signage & Lobbies: VESA-mountable for high-impact presentations in corporate/retail spaces

Engineering Workstations: COM port supports legacy industrial equipment and control systems

Executive Desks: premium gunmetal/black design suits professional environments with clutter-free setup

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

Product NameLenovo AIO-A807
Product ColorBlack/Gun color
Operating SystemWindows 10/11 64-bit
Display Manufacturer/ModelCSOT SG2701G01-2 (optional)
Display Size/Ratio27 inch 16:9 LED backlight widescreen
Display ModeVA
Diagonal Size68.6mm
Resolution2560×1440@60Hz
Refresh Rate60Hz
Default Color Temperature6500K(±750K）
Screen Size596.736(H) x 335.664(V)mm
Dot Pitch0.077(H)×0.2331(V) mm
Display Color16.7M
Brightness (Typ.)250 cd/m²
Contrast4000:1[Typ.]
Response Time16ms[Typ.]
Viewing Angle178°(H)/178°(V)[Typ.] (CR≥10)
Uniformity75%[Typ.] & 70%[Min.]
CPUIntel Core 12th Generation I5-12400 (optional)
CPU Clock Rate2.5GHz
Level 3 Cache18MB
Production Process10nm
Number of CoresSix cores and twelve threads
Display ChipIntel HD Graphics 730
TDP Power Consumption65W
Motherboard ModelJW H610I V2.0 (optional)
ChipsetIntel H610
Memory InterfaceSO-DIMM DDR4 memory slot*2 (supports 2666/2933/3200MHz memory frequency) 32G MAX
Storage InterfaceM.2 2242/2280 SSD*1, 2.5inch SATA SSD/HDD*1
Network InterfaceRJ-45 (10/100/1000M Ethernet Lan)*1
WIFI InterfaceM.2 2230*1
USB PortUSB 3.2*2, USB 3.0*2
Function PortCOM*1
Video PortHDMI OUT*1
Audio PortsHeadphone jack ∮3.5mm*1 Microphone jack ∮3.5mm*1
Power InterfaceDC-in (5525) 19V input x1
MemoryKingBank DDR4 PC4-3200MHz 16GB (optional)
Hard DiskKingBank PCIe Gen3x4 M.2 2280 KP230 512GB(NVME) (optional)
GraphicsIntegrated Graphics
WIFIFn-Link 6252M-PUB RTL8852BE-CG,a/b/g/n/ac/ax,Wi-Fi+BT 5.2, 2T2R, 5.8GHz/5.1GHz/2.4GHz
Extended USB PortUSB 2.0*4(bottom)
Speaker Function4Ω/3W * 2
CameraNA
Power AdapterHuntkey HKA15019079-6C (19.0Vdc, 7.9A, 150.1W)
Decorative StripsAluminum profile, anodized surface_black, screen printing color Pantone 8403C
Middle FrameABS PA-757 Gunmetal, Glossy
Middle Frame CoverPC FL5105-v2 Black, textured, silk screen Pantone 8403C
Back Shell FrameABS PA-757 Black_With heat dissipation holes
Back CoverABS PA-757 Gunmetal, glossy; screen printing Pantone 485C
I/O BezelSGCC, powder coated surface_black
BracketAluminum profile (kit, round, wire hole), surface anodized_gun color
BaseAluminum alloy (square), gunmetal color + ABS PA-757 red decorative parts
Product SizeWith base bracket: L614*W188*H467mmW/O base bracket: L614*W58*H367mm (subject to the final product)
VESA Mount100mmx100mm
Axis Angle-5°~15°（±3°）
Height AdjustmentNA
Horizontal/Vertical RotationNA
Product Net Weight/Gross Weight6.65 kg / 8.95 kg (without keyboard and mouse), 10.15 kg (with keyboard and mouse)
