Lenovo AIO-A802

21.45″ FHD Hybrid All-in-One PC | Optional 12th Gen Intel® Core™ i5 Power | WiFi 6 & VESA Mount | Dual-Color Design

Overview

Lenovo AIO-A802 is a well – designed computing device suitable for a variety of usage scenarios. With its 21.45″ VA panel and a 1920×1080 resolution at 60Hz refresh rate, it offers a clear visual experience. It comes with options for powerful components like the Intel Core 12th Generation I5 – 12400 CPU, making it capable of handling various tasks. This microcomputer is an excellent choice for both home and office use.

Key Features

  • 21.45″ full HD VA screen (1920×1080), 178° wide viewing angle, vivid colors, support VESA wall mounting, save space
  • Equipped with HDMI, COM, Gigabit Ethernet port, dual-band Wi-Fi and multiple USB ports, easily connect to office, education and home devices
  • Optional 12th generation i5-12400 processor (6 cores and 12 threads), support 32GB DDR4 memory and M.2+SATA dual hard drive expansion

Application Scenarios

Home Office Hub: handles remote work, video calls, and productivity tasks with modern connectivity

SMB Workstations: manages business software and multitasking with optional i5 CPU power

Educational Environments: space-saving solution for classrooms or computer labs

Retail & Hospitality: supports POS systems and kiosks via COM port and VESA mounting

Creative Starter Setup: runs light design/editing software with color-accurate display

Hybrid Home Use: doubles as entertainment and productivity center with HDMI-out

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

Product NameLenovo AIO-A802
Product ColorBlack/Gun color
Operating SystemWindows 10/11 64-bit
Manufacturer/ModelCSOT SG2151B05-2 (optional)
Size/Ratio21.45 inch 16:9LED backlit widescreen
Panel TypeVA
Diagonal size54.5cm
Resolution1920×1080@60Hz
Refresh Rate60Hz
Default Color Temperature6500K(±750K）
Display Surface478.656(H) x 260.28(V)mm
Pixel Pitch0.0831(H)×0.241(V) mm
Color Depth16.7M
Brightness250 cd/m²
Contrast Ratio3000:1[Typ.] / 2000:1[Min.]
Response Time11 ms[Typ.]
View Angle (H/V)178°(H)/178°(V)[Typ.] (CR≥10)
Uniformity75%[Typ.] & 70%[Min.]
CPUIntel Core 12th Generation I5-12400 (optional)
CPU Clock Rate2.5GHz
Level 3 Cache18MB
Production Process10nm
Number of CoresSix cores and twelve threads
Display ChipIntel HD Graphics 730
TDP Power Consumption65W
Motherboard ModelJW H610I V2.0
ChipsetIntel H610
Memory InterfaceSO-DIMM DDR4 memory slot*2 (supports 2666/2933/3200MHz memory frequency) 32G MAX
Storage InterfaceM.2 2242/2280 SSD*1, 2.5inch SATA SSD/HDD*1
Network InterfaceRJ-45 (10/100/1000M Ethernet Lan)*1
WIFI InterfaceM.2 2230*1
USB PortUSB3.2*2, USB3.0*2
Function PortCOM*1
Video PortHDMI OUT*1
Audio PortsHeadphone jack ∮3.5mm*1 Microphone jack ∮3.5mm*1
Power InterfaceDC-in (5525) 19V input x1
MemoryKingBank DDR4 PC4-3200MHz 16GB (optional)
Hard DiskKingBank PCIe Gen3x4 M.2 2280 KP230 512GB(NVME) (optional)
GraphicsIntegrated Graphics
WIFIFn-Link 6252M-PUB RTL8852BE-CG,a/b/g/n/ac/ax,Wi-Fi+BT5.2, 2T2R, 5.8GHz/5.1GHz/2.4GHz
Extended USB PortUSB2.0*4(bottom)
Speaker Function4Ω/3W * 2
CameraNA
Power AdapterHuntkey HKA15019079-6C (19.0Vdc, 7.9A, 150.1W)
Decorative StripsAluminum profile, anodized surface_black, screen printing color: Pantone 8403C
Middle FrameABS PA-757 Gunmetal, Glossy
Middle Frame CoverPC FL5105-v2 Black, textured, silk screen Pantone 8403C
Back Shell FrameABS PA-757 Black_With heat dissipation holes
Back CoverABS PA-757 Gunmetal, glossy; screen printing Pantone 485C
I/O BezelSGCC, powder coated surface_black
StandAluminum profile (kit, round, wire hole), surface anodized_gun color
BaseAluminum alloy (square), gunmetal color + ABS PA-757 red decorative parts
Product SizeWith base bracket: L493*W188*H414mmW/O base bracket: L493*W57*H287mm (Subject to the final product)
VESA Mount100 mmx100 mm
Axis Angle-5°~15°（±3°）
Height AdjustmentNA
Horizontal/Vertical RotationNA
Product Net Weight Gross Weight5.2 kg / 7.3 kg (without keyboard and mouse), 8.45 kg (with keyboard and mouse)
