AOC BladeSeries AIO-A2706
27” Ultra-Slim Business All-in-One PC | Full Range of Intel® Processors Supported | Tool-Free Stand | VESA Mount Ready
Overview
Designed for modern workspaces, AOC Blade Series AIO-A2706 ultra-slim monitor combines minimalist aesthetics with functional versatility. Featuring a razor-thin 2mm bezel and lightweight build, it delivers an immersive viewing experience while adapting effortlessly to any environment. The tool-free stand and VESA compatibility ensure quick setup, whether on a desk, wall, or monitor arm. Engineered with smart ventilation and a premium black finish, this display excels in offices, conference rooms, and flexible workstations.
Key Features
Application Scenarios
Customization Options
TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.
Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.
| Product Model | AOC Blade Series AIO-A2706 | ||||
| Product Color | Black | ||||
| OS | Only supports UEFI mode systems | ||||
| Panel | Display Manufacturer/Model | CSOT SG2151B05-2 (optional) | |||
| Display Size/Ratio | 21.45-inch 16:9 LED-backlit widescreen | ||||
| Display Mode | VA | ||||
| Diagonal Size | 54.5CM | ||||
| Resolution | 1,920×1,080@60Hz | ||||
| Refresh Rate | 60Hz | ||||
| Default Color Temperature | 6,500K | ||||
| Screen Size | 478.656(H) x 260.28(V)mm | ||||
| Dot Pitch | 0.0831*0.241mm | ||||
| Display Color | 16.7M | ||||
| Brightness (Max.) | ≥220cd/㎡ | ||||
| Contrast Ratio | 3,000:1[Typ.] / 2000:1[Min.] | ||||
| Response Time | 6.5ms | ||||
| Color Field (1931) | NTSC: 72% | ||||
| Viewing Angle | 178°(H)/178°(V)(CR≧10) | ||||
| Uniformity | 80%[Typ.] & 75%[Min.] | ||||
| Configuration | CPU | CPU | Intel i5-1035G1 | Intel Celeron N5095A | Intel N95 |
| CPU Frequency | 1.0GHz (Maximum turbo frequency 3.6GHz) | 2.0GHz(Maximum turbo frequency 2.9GHz) | 2.0GHz(Maximum turbo frequency 3.4GHz) | ||
| Level 3 Cache | 6MB | 4MB | 6MB | ||
| Production Process | 10nm | 10nm | 10nm | ||
| Number of Cores | Quad-core and eight-thread | Quad-core and four-thread | Quad-core and four-thread | ||
| Display chip | Intel Iris Plus | Intel UHD Graphics | Intel UHD Graphics | ||
| TDP Power Consumption | 15W | 15W | 15W | ||
| Motherboard | Motherboard Model | IP3_IA10 | IP3_JA10 | IP3_DNA10 | |
| Size | 170*88mm | ||||
| Chipset | Intel Ice Lake U 1035G1 | Intel Ice Lake U N5095A | Intel Alder Lake N N95 | ||
| Memory Interface | SO-DIMM DDR4 memory slot*1 (Up to DDR4 3200MHz 16GB) | SO-DIMM DDR4 memory slot*1(Up to DDR4 2933MHz 16GB) | SO-DIMM DDR4 memory slot*1(Up to DDR4 3200MHz 16GB) | ||
| Storage Interface | M.2 2242/2280 SSD*1,2.5inch SATA SSD/HDD*1 | ||||
| Network Interface | RJ-45(10/100/1000M Ethernet Lan)*1 | ||||
| WIFI Interface | M.2 2230*1 | ||||
| USB Port | USB3.0*4 | ||||
| Function Port | NA | ||||
| Video Port | HDMI OUT*1 | ||||
| Audio Ports | Headphone + microphone two-in-one interface ∮3.5mm*1 | ||||
| Power Interface | DC-in(5525)12V input x1 | ||||
| Memory | DDR4 2666MHz 8GB (optional) | ||||
| Hard Disk | M.2 SSD 256GB (optional) | ||||
| Graphics | Integrated Graphics | ||||
| WIFI Model | Fn-Link_6221M-PUC(RTL8821CE) dual antenna (2.4GHz/5GHz 802.11 a/b/g/n/ac, Bluetooth 2.1/5.0) (optional) | ||||
| Extended USB Port | USB2.0*2 (side) | ||||
| Speaker Function | 4Ω/3W * 2 | ||||
| Camera | NA | ||||
| Power Adapter | 12V,5A 60W | ||||
| Structure | Front Frame/Front Decorative Strip | ABS, black, textured | |||
| Frame | ABS, black, textured | ||||
| Back Plate | SGCC, black spray paint, textured surface | ||||
| Middle Frame | ABS, black, brushed | ||||
| Back Shell | ABS, black, textured | ||||
| Bracket | Square quick release, aluminum alloy, black spray paint, textured surface | ||||
| Base | Square,Aluminum alloy,Black paint,Texture surface | ||||
| Product Net Weight/Gross Weight | 3.7Kg / 5.1Kg (subject to the final product) | ||||
| Product Size | With base bracket: 490(W)x160(D)x395(H)mmWithout base bracket: 490(W)x38(D)x280(H)mm | ||||
| Packing Size | L607mm*W142mm*H432mm(Subject to the final product) | ||||
| VESA Mount | 75mm*75mm | ||||
| Axis Angle | -5°~15°(±3°) | ||||
| Height Adjustment | NA | ||||
| Horizontal/Vertical Rotation | NA | ||||
| Safety | CCC, Energy Efficiency, RoHS | ||||
