AOC Blade Series AIO-L2206

27” FHD Business All-in-One PC | Full Range of Intel® Processors Supported | 2mm Ultra-Narrow Bezel | Quick-Assembly Stand

Overview

Designed for productivity and modern workspaces, the AOC 27B2H features a 27″ Full HD display with ultra-slim bezels for maximum screen real estate. Its premium black finish and sturdy metal stand offer both elegance and durability, while the screwless assembly ensures quick setup. Optimized airflow keeps the monitor cool and quiet, making it ideal for office environments. With VESA mount compatibility, it adapts to desks, walls, or monitor arms for flexible workspace solutions.

Key Features

  • 27” Full HD large screen for wide, clear visuals
  • Ultra-slim profile with premium black aesthetics
  • Micro-bezel (2mm) maximizes screen space
  • Heavy-duty metal stand with quick, screwless assembly
  • Thoughtful airflow design enhances heat dissipation silently
  • Supports 75×75mm VESA mount – wall or monitor arm compatible

Application Scenarios

Corporate Workstations – The 27″ Full HD large screen provides expansive workspace for multitasking with documents, spreadsheets, and presentations

Conference Rooms & Meeting Spaces – Ultra-slim profile and micro-bezel design create a professional, distraction-free viewing experience

Home Office & Remote Work – Premium black aesthetics and space-saving design blend seamlessly into modern home setups

Digital Signage & Retail Displays – VESA mounting support allows flexible installation for advertising or information screens

Call Centers & Shared Workspaces – Heavy-duty metal stand ensures stability, while silent cooling maintains a quiet environment

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

Product NameAOC Blade Series AIO-L2206
Product ColorBlack
OSOnly supports UEFI mode systems
PanelDisplay Manufacturer/ModelBOE DV270FHB-P20 (optional)
Display Size/Ratio27-inch 16:9 LED-backlit widescreen
Display ModeADS
Diagonal Size68.6CM
Resolution1,920×1,080
Refresh Rate60Hz
Default Color Temperature6,500K±700
Screen Size597.888(H) x 336.312(V)mm
Dot Pitch0.3114*0.3114mm
Display Color16.7M
Brightness(Max.)≥250cd/㎡
Contrast Ratio1,000:1[Typ.] / 700:1[Min.]
Response Time14ms [GTG]
Color Field (1931)NTSC: 72%
Viewing Angle178°(H)/178°(V)(CR≧10)
Uniformity80%[Typ.] & 75%[Min.]
ConfigurationCPUCPUIntel i5-1035G1Intel Celeron N5095AIntel N95
CPU Frequency1.0GHz (Maximum turbo frequency 3.6GHz)2.0GHz (Maximum turbo frequency 2.9GHz)2.0GHz (Maximum turbo frequency 3.4GHz)
Level 3 Cache6MB4MB6MB
Production Process10nm10nm10nm
Number of CoresQuad-core and eight-threadQuad-core and four-threadQuad-core and four-thread
Display chipIntel Iris PlusIntel UHD GraphicsIntel UHD Graphics
TDP Power Consumption15W15W15W
MotherboardMotherboard ModelIP3_IA10IP3_JA10IP3_DNA10
Size170*88mm
ChipsetIntel Ice Lake U 1035G1Intel Ice Lake U N5095AIntel Alder Lake N N95
Memory InterfaceSO-DIMM DDR4 memory slot*1(Up to DDR4 3200MHz 16GB)SO-DIMM DDR4 memory slot*1 (Up to DDR4 2933MHz 16GB)SO-DIMM DDR4 memory slot*1(Up to DDR4 3200MHz 16GB)
Storage InterfaceM.2 2242/2280 SSD*1,2.5inch SATA SSD/HDD*1
Network InterfaceRJ-45(10/100/1000M Ethernet Lan)*1
WIFI InterfaceM.2 2230*1
USB PortUSB3.0*4
Function PortNA
Video PortHDMI OUT*1
Audio PortsHeadphone + microphone two-in-one interface ∮3.5mm*1
Power InterfaceDC-in(5525)12V input x1
MemoryDDR4 2666MHz 8GB (Optional)
Hard DiskM.2 SSD 256GB (Optional)
GraphicsIntegrated Graphics
WIFI ModelRTL8821CE dual antenna (2.4GHz/5GHz 802.11 a/b/g/n/ac, Bluetooth 2.1/5.0) (optional)
Extended USB PortUSB2.0*2 (side)
Speaker Function4Ω/3W * 2
CameraNA
Power Adapter12V,7A 84W
StructureFront Frame/Front Decorative StripABS, black, textured
FrameABS, black, textured
Back PlateSGCC, black spray paint, textured surface
Middle FrameABS, black, brushed
Back ShellABS, black, textured
BracketSquare quick release, aluminum alloy, black spray paint, textured surface
BaseSquare,Aluminum alloy,Black paint,Texture surface
Product Net Weight/Gross Weight5.1Kg / 6.8Kg (Subject to the final product)
Product SizeWith base bracket: 610(W)x160(D)x456(H)mmWithout base bracket: 610(W)x39(D)x361(H)mm
Packing SizeL725mm*W145mm*H512mm(Subject to the final product)
VESA Mount75mm*75mm
Axis Angle-5°~15°(±3°)
Height AdjustmentNA
Horizontal/Vertical RotationNA
SafetyCCC, Energy Efficiency, RoHS
