AOC Blade Series AIO-A2406

23.8” FHD Professional All-in-One PC | Full Range of Intel® Processors Supported | 2mm Ultra-Narrow Bezel | VESA Compatible

Overview

AOC Blade Series AIO-A2406 23.8″ Professional monitor delivers essential business performance with its Full HD LED panel and ultra-narrow 2mm bezels. Designed for productivity, its space-saving slim profile and tool-free base assembly make it ideal for high-density work environments. The thoughtful ventilation system ensures reliable operation, while VESA compatibility offers flexible mounting options to suit any workspace configuration.

Key Features

  • 23.8” Full HD LED screen with wide viewing angles
  • 2mm ultra-narrow bezel – more screen, less distraction
  • Ultra-slim profile for a modern workspace
  • Screwless die-cast base allows for quick and stable setup
  • Clean ventilation layout integrated into the chassis
  • Compatible with 75×75mm VESA wall mounts

Application Scenarios

Corporate Workstations – The 23.8″ Full HD screen with wide viewing angles is perfect for shared office spaces and cubicles

Financial Trading Desks – Ultra-narrow bezel enables seamless multi-monitor configurations for data-intensive applications

Home Office Solutions – Slim profile and clean aesthetics complement modern home workspaces

Educational Institutions – Simple VESA mounting allows flexible classroom or lab installations

Retail Digital Signage – Bright LED display with stable base works well for point-of-sale or information displays

Customization Options

Branding – Logo, boot animation, packaging

BIOS Custom – UI, splash screen, default settings

I/O Custom – Optional COM/VGA, USB config

OS Preload – Windows / Linux / Driver Bundle

Localization – Language, manuals, after-sales docs

TENFLY provides full customization services including logo printing, BIOS interface, I/O configuration, OS pre-installation, and packaging. Whether for education tenders, enterprise deployment, or OEM partnerships, we deliver tailored hardware and software solutions based on your exact needs.

Please note: Product features and specifications may vary by project scope or regional requirements. Final configuration is subject to customer confirmation.

Product ModelAOC Blade Series AIO-A2406
Product ColorSilver White
OSOnly supports UEFI mode systems
PanelDisplay Manufacturer/ModelBOE DV238FHB-N30 (optional)
Display Size/Ratio23.8-inch 16:9 LED-backlit widescreen
Display ModeADS
Diagonal Size60.5CM
Resolution1,920×1,080@60Hz
Refresh Rate60Hz
Default Color Temperature6,500K
Screen Size527.04(H) x 296.46(V)mm
Dot Pitch0.2745*0.2745mm
Display Color16.7M
Brightness(Max.)≥220cd/㎡
Contrast Ratio1,000:1[Typ.] / 700:1[Min.]
Response Time14ms [GTG]
Color Field (1931)sRGB: 96%
Viewing Angle178°(H)/178°(V)(CR≧10)
Uniformity75%[Typ.] & 70%[Min.]
ConfigurationCPUCPUIntel i5-1035G1Intel Celeron N5095AIntel N95
CPU Frequency1.0GHz(Maximum turbo frequency 3.6GHz)2.0GHz(Maximum turbo frequency 2.9GHz)2.0GHz(Maximum turbo frequency 3.4GHz)
Level 3 Cache6MB4MB6MB
Production Process10nm10nm10nm
Number of CoresQuad-core and eight-threadQuad-core and four-threadQuad-core and four-thread
Display chipIntel Iris PlusIntel UHD GraphicsIntel UHD Graphics
TDP Power Consumption15W15W15W
MotherboardMotherboard ModelIP3_IA10IP3_JA10IP3_DNA10
Size170*88mm
ChipsetIntel Ice Lake U 1035G1Intel Ice Lake U N5095AIntel Alder Lake N N95
Memory InterfaceSO-DIMM DDR4 memory slot*1(Up to DDR4 3200MHz 16GB)SO-DIMM DDR4 memory slot*1(Up to DDR4 2933MHz 16GB)SO-DIMM DDR4 memory slot*1(Up to DDR4 3200MHz 16GB)
Storage InterfaceM.2 2242/2280 SSD*1,2.5inch SATA SSD/HDD*1
Network InterfaceRJ-45(10/100/1000M Ethernet Lan)*1
WIFI InterfaceM.2 2230*1
USB PortUSB3.0*4
Function PortNA
Video PortHDMI OUT*1
Audio PortsHeadphone + microphone two-in-one interface ∮3.5mm*1
Power InterfaceDC-in(5525)12V input x1
MemoryDDR4 2666MHz 8GB (optional)
Hard DiskM.2 SSD 256GB (optional)
GraphicsIntegrated Graphics
WIFI ModelRTL8821CE dual antenna (2.4GHz/5GHz 802.11 a/b/g/n/ac, Bluetooth 2.1/5.0) (optional)
Extended USB PortUSB2.0*2 (side)
Speaker Function4Ω/3W * 2
CameraNA
Power Adapter12V,5A 60W
StructureFront Frame/Front Decorative StripABS, white, textured
FrameABS, white, textured
Back PlateSGCC, white spray paint, textured surface
Middle FrameABS, white, textured
Back ShellABS,Silver,Texture
BracketSquare quick release, aluminum alloy, silver spray paint, textured surface
BaseSquare, Aluminum alloy, Silver spray paint, Texture surface
Product Net Weight/Gross Weight4.2Kg / 5.8Kg (Subject to the final product)
Product SizeWith base bracket: 537(W)x160(D)x434(H)mmWithout base bracket: 537(W)x39(D)x319(H)mm
Packing SizeL645mm*W139mm*H482mm (Subject to the final product)
VESA Mount75mm*75mm
Axis Angle-5°~15°(±3°)
Height AdjustmentNA
Horizontal/Vertical RotationNA
SafetyCCC, Energy Efficiency, RoHS
